PRODUCT FEATURES:
- Telescopic spindle, interference contour remains unchanged
- Central, simple programming without zero-point offset
- The allowance of the material is symmetrically distributed
- Accessibility of the workpiece depends on the chuck capacity
- Symmetrical construction shape= workpiece remains central and parallel
- Support height of the workpiece 192 mm
- Quick change jaw system, tool-free jaw changes due to quick-action closure within 10 seconds per jaw pair
- Reversible jaws: for min. / max. chuck capacities with one pair of jaws
- Constant clamping force via lubrication-free, coated telescopic spindle
- Provided as standard with locating holes for a zero point clamping system, inside micrometre 200
- Attachment to machine table with mounting raster 50/63mm for fitting bolt/cylinder screws or clamping shoes
- Integrated scaling for fine adjustment of the central position
- Low weight (without jaws): K =17.5 kg / M=19.5 kg
- Clamping force 30 kN at 100 Nm linear
- Operation with torque wrench
- Ideal for use on 5-axis machining centres
- Conventional clamping and Gripp clamping possible
